Adjustable Screw Piles

For more details, pls email:rukin@grengysolar.com

Adjustable screw piles, also known as telescopic helical piles, are an innovative variation of traditional helical piles. Here's a detailed look at what they are:

Design

• Telescopic Shafts: At the heart of adjustable screw piles are telescopic or extendable shafts. These consist of an inner and outer section that can slide relative to one another. The outer shaft is typically the main load-bearing part, while the inner shaft allows for height adjustment. Both sections are made of high-strength steel to ensure they can withstand significant loads.
• Helical Plates: Like standard helical piles, adjustable versions have helical plates attached to the lower part of the shaft. These plates are designed to penetrate the soil and transfer loads, with their size, number, and pitch customized according to the soil type and project requirements.

Installation Process

• Initial Insertion: The pile is first installed in the ground using a hydraulic or mechanical rotary device, similar to traditional helical piles. The operator screws the pile into the soil until it reaches a certain depth, achieving initial stability.
• Adjustment: Once the base of the pile is in place, the telescopic feature can be utilized. Hydraulic or mechanical actuators are used to extend or retract the inner shaft, allowing for precise height adjustment. This can be done even after the pile has been initially inserted into the ground, which is a major advantage over fixed-height piles.

Advantages

• Versatility in Uneven Terrain: In construction sites with uneven ground levels, adjustable screw piles can be set to different heights. This adaptability simplifies the process of creating a level foundation for structures like decks, sheds, or small buildings, eliminating the need for complex grading or additional underpinning.
• Future-Proofing: If there are potential changes in the elevation of the ground over time, perhaps due to soil settlement or erosion, the height of the pile can be readjusted. This feature also comes in handy if the superstructure needs to be modified or raised at a later stage.
• Ease of Installation: They retain the quick and relatively non-invasive installation benefits of regular helical piles. The ability to make on-the-fly adjustments during installation reduces the chances of errors and rework.
• Cost Savings: By enabling a single type of pile to accommodate various height requirements, there's no need to stock multiple fixed-height pile sizes. Additionally, the reduced need for ground leveling and complex foundation work can lead to significant cost savings, especially in smaller projects.

Applications

• Residential Construction: Commonly used for building decks, porches, and small outbuildings where the ground may not be perfectly flat. Homeowners can quickly and affordably install adjustable screw piles to create a stable foundation.
• Outdoor Structures: For structures such as pergolas, gazebos, and light poles, adjustable screw piles ensure that the installation can be tailored to the exact height requirements while also accounting for any future changes in the ground level.
• Industrial and Commercial Sites: In some industrial setups, adjustable screw piles can be used to support machinery or equipment racks. Their ability to be adjusted helps in compensating for floor or ground irregularities, ensuring the equipment is properly aligned and stable.
