Solar Mounting Screw Pile
Items: Solar Mounting Screw Pile
Main Material: Hot-galvanized Steel Q235/Q355, High Class Hot-galvanized average 85μ+
Lead Time: 7-10 days
OEM & Sample: Available
Supply Capacity: 3000 PCS/DAY
- Fast Delivery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Fast, Concrete-Free Foundations for Ground PV Systems
Secure your ground-mounted solar arrays with our heavy-duty Solar Panel Ground Anchor system. Engineered for commercial and utility-scale projects, this concrete-free foundation delivers maximum pull-out resistance and long-term stability in all soil types.
Manufactured from high-strength structural steel with premium corrosion protection, our Solar Panel Ground Anchor eliminates concrete curing wait times-slashing installation labor and reducing overall system costs.
Key Features
- High Structural Resistance: Premium hot-dip galvanized steel ensures superior wind, snow, and soil corrosion resistance for a 25+ year service life.
- Rapid Installation: Screws directly into the soil using mechanical rigs, cutting deployment time by up to 50% without concrete delays.
- Flexible Terrain Performance: Engineered helical flange provides exceptional pull-out capacity on flat land, slopes, sand, and clay.
- Eco-Friendly Foundation: Minimal ground disturbance with 100% removal or reuse capability upon project decommissioning.
- Universal Racking Fit: Custom flange plates connect seamlessly to standard aluminum rails and galvanized steel mounting structures.
For more details, pls email rukin@grengysolar.com
Product Specifications
| Parameter Item | Technical Specifications |
| Material Base | Certified Structural Steel (Q235B) |
| Anti-Corrosion | Hot-Dip Galvanized (HDG) average thickness ≥85μ |
| Dimensions | Diameter: Ф76mm/Ф89mm/Ф114mm |
| Length Range | 1000mm to 3000mm (Customizable) |
| Flange Options | Round, Square, Hexagonal, U-Shape, or Adjustable |
| Design Standards | ASCE/SEI 7, AS/NZS 1170.2, Eurocode 1 |
| Lifespan / Warranty | 25+ Years Lifespan / 15-Year Structural Warranty |
| MOQ Constraint | No MOQ (Zero Minimum Order Quantity) |
Production Video
Brief introduction of our factory
Xiamen Grengy Photovoltaic Technology Co., Ltd., founded in 2007, is a trusted renewable energy partner. We specialize in designing and manufacturing high-performance PV mounting systems for safety, durability, and maximum energy output. Our dedicated R&D team provides customized solutions for global residential, commercial, and utility-scale projects.
